USB Controlled Attenuators up to 20 GHz
Digitally controlled USB attenuators provide precise signal conditioning for RF and microwave applications up to 20 GHz. The Vaunix product line offers flexible channel configurations and advanced control interfaces designed for test laboratories, system integration, and automated measurement environments requiring dynamic attenuation control.
Technical Specifications
- Frequency Range: DC to 20 GHz, covering C-band, X-band, Ku-band, and Ka-band applications
- Channel Options: Available in 1, 4, 8, 12, and 16-channel configurations
- Attenuation Range: Up to 120 dB with 0.1 dB step resolution
- Control Interface: USB and Ethernet connectivity for remote operation and automated test sequences
- Specialized Configurations: Handover test systems supporting up to 512 channels; mesh network attenuators; rackmount form factors
Applications
- 5G/6G & Telecommunications: Dynamic signal level management for next-generation wireless system testing and network emulation
- SATCOM: Link budget simulation and communication system verification
- Defense & Aerospace: RF component characterization requiring repeatable attenuation profiles
- Research & Development: Amplifier gain measurement, device performance validation, and multi-element RF network characterization
USB and Ethernet connectivity enables seamless integration into automated measurement systems, while extensive channel density options support both single-component testing and complex multi-channel applications. bq-microwave distributes the complete Vaunix attenuator portfolio across Europe, providing technical support and product availability for RF testing infrastructure requirements.
Product Data Sheet
Technical specifications as PDF
