Bias Tee 500 KHz-12 GHz, BT-H01 by Taylor Microwave

BT-H01 Bias Tee from Taylor Microwave – Reliable Power Injection up to 12 GHz

BQ-Microwave is proud to offer the BT-H01 Bias Tee by Taylor Microwave, a robust and compact solution designed for RF and microwave systems operating up to 12 GHz. Engineered to inject DC power into RF signal paths without compromising signal integrity, this bias tee is ideal for high-frequency applications where performance and reliability are essential.

Key Specifications – BT-H01 Bias Tee

• Frequency Range: 500 kHz to 12 GHz

• Insertion Loss: 2.25 dB

• VSWR: 2.0:1 max

• Isolation: Minimum 30 dB

• DC Current Handling: Up to 2.5 A at a maximum of 250 V

• Input Power: Up to 30 Watts CW

• Connectors: SMA-female

Optimized for Demanding Applications

The BT-H01 is an excellent choice for:

• RF and microwave testing environments

• Biasing low-noise amplifiers, photodiodes, and active antennas

• Communication systems and signal monitoring setups

• Lab and field measurement systems requiring broadband DC bias injection

Why Choose Taylor Microwave’s BT-H01?

With its wide frequency range, excellent isolation, and high DC current handling capacity, the BT-H01 delivers reliable performance across a variety of use cases. The SMA-female connectors ensure easy integration into existing RF systems, while the compact design supports both portable and fixed installations.

Available now from bq-microwave

As the trusted distributor for Taylor Microwave products in Europe, bq-microwave offers immediate access to the BT-H01 along with expert support and consultation for your RF/microwave needs.

For custom solutions or technical inquiries, contact us at info@bq-microwave.de or use the contact for on our website.

Please click below for downloading the current PDF sheet.
