Broadband Directional Couplers up to 67 GHz
Directional couplers are essential passive components in RF and mmWave systems, enabling precise power monitoring, signal sampling, and transmit/receive isolation across broadband frequency ranges. These extended bandwidth couplers reach up to 67 GHz, addressing the requirements of next-generation wireless, satellite communication, and test systems that demand reliable coupling performance across ultra-wideband applications.
The broadband operation simplifies system design by reducing the need for multiple single-band components while maintaining consistent directivity and coupling characteristics across the entire operational bandwidth. Compact form factors ensure compatibility with standard RF connector interfaces for straightforward integration.
Technical Specifications
- Frequency coverage: Multiple configurations available: 1–18 GHz, 1–40 GHz, and 1–67 GHz
- Broadband operation: Minimizes frequency-dependent performance variations
- Connectors: Compatible with SMA and larger standard RF interfaces
- Performance: Low insertion loss with controlled directivity across the entire band
- Response characteristics: Flat amplitude and phase response
- Custom options: Specific frequency ranges, coupling ratios, and impedance specifications available
Applications
- 5G/6G infrastructure: Power monitoring and signal distribution in base station transceivers
- SATCOM systems: Uplink/downlink isolation and power measurement in satellite terminals
- Radar and sensing: TX/RX port isolation in phased-array and automotive radar
- mmWave test and measurement: Signal sampling and power detection in laboratory environments
- Defense and aerospace: Electronic warfare systems requiring broadband coupling across extended frequency ranges
Multiple bandwidth options enable engineers to select couplers precisely matched to their operational requirements, whether supporting narrowband specialized applications or ultra-wideband systems spanning octave-level frequency ranges.
bq-microwave offers these broadband directional couplers as European distributor. For custom frequency bands, coupling ratios, or environmental specifications, contact our technical team for detailed product documentation and performance data.
