Frequency Multipliers up to 400 GHz in Coaxial and Waveguide Formats
Frequency multipliers are essential components for RF and mmWave systems operating at sub-terahertz frequencies. bq-microwave offers comprehensive solutions in both coaxial and waveguide configurations, with waveguide implementations now reaching up to 400 GHz and coaxial designs supporting frequencies through 67 GHz. These components provide critical signal generation and conversion capabilities for demanding applications where direct oscillator availability remains limited or economically prohibitive.
Technical Specifications
- Frequency Range: Waveguide multipliers up to 400 GHz across WR22 through WR06 and higher waveguide standards; coaxial multipliers up to 67 GHz with SMA connector compatibility
- Multiplication Factors: Supporting x2, x3, x4, and higher-order multiplier designs
- Output Power: Typical power levels ranging from +10 to +20 dBm depending on frequency band
- Conversion Efficiency: Optimized designs minimizing DC power consumption and thermal dissipation
- VSWR Performance: Input and output return loss specifications ensure seamless system integration
- Availability: Substantial inventory with expedited lead times
Application Areas
- 5G/6G & Telecommunications: Signal generation and upconversion for millimeter-wave frequency bands
- SATCOM Systems: Ka-band and Q/V-band satellite transponder equipment
- Defense & Radar: High-frequency sensing and surveillance applications
- Test & Measurement: Laboratory signal sources and calibration systems
- Sub-THz Applications: Emerging frequency bands approaching THz operational windows
The availability of both waveguide and coaxial implementations ensures flexibility across diverse system architectures. Waveguide variants deliver superior power handling and efficiency at the highest frequency bands, while coaxial solutions offer compact form factors and simplified integration for lower-frequency applications.
As European distributor, bq-microwave maintains substantial stock positions and supports rapid procurement cycles. For detailed specifications and technical consultation, contact our team.
