WR6 Waveguide Low Noise Amplifier 110–170 GHz Bench-Top Version
bq-microwave has expanded its D-Band amplifier portfolio with WR6 waveguide low noise amplifiers (LNAs) in bench-top configuration. These compact units address the growing demand for accessible millimeter-wave solutions in the 110–170 GHz frequency range, enabling high-performance amplification without extensive infrastructure investment.
The bench-top format integrates power conditioning and standard waveguide interfaces, reducing system complexity and accelerating deployment in laboratory and development environments.
Technical Specifications
- Frequency Range: 110–170 GHz (D-Band)
- Waveguide Standard: WR6
- Gain Options: 18 dB or 33 dB configurations
- Noise Figure: 6 dB
- Power Supply: +220V AC/DC adapter included
- Format: LCBT (Low Cost, Compact Bench-Top) with integrated power conditioning
- Waveguide Interface: Standard WR6 connectors
The dual-gain architecture provides flexibility across diverse measurement scenarios, while the 6 dB noise figure ensures minimal signal degradation in sensitive receiver chains and spectral analysis applications.
Application Areas
- 5G/6G Research: Development and prototype evaluation of millimeter-wave communication systems
- SATCOM: Ground station testing and satellite communication subsystem validation
- Defense & Aerospace: RF subsystem characterization and radar testing
- Research & Development: Material science, imaging experiments, and academic laboratory setups requiring D-Band coherent sources
The bench-top configuration eliminates the need for external auxiliary equipment, reducing total system cost and accelerating project timelines. bq-microwave offers these WR6 LNA modules as part of its European distribution portfolio for RF and millimeter-wave components. For detailed technical documentation or application-specific guidance, contact us at info@bq-microwave.de.
